Lenovo Legion Y540-15IRH-PG0 81SY
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Lenovo Legion Y540-15IRH-PG0 81SY
- Core i7 9750H / 2.6 GHz
- Win 10 Pro 64-bit
- 16 GB RAM
- 256 GB SSD NVMe + 1 TB HDD
- 15.6" IPS 1920 x 1080 (Full HD) @ 60 Hz
- GF GTX 1650
- 802.11ac, Bluetooth
- black
- kbd: US
| Additional Details | |
|---|---|
| Mfr Part #: | 81SY0005US |
| SHI Part #: | 37280864 |
| Category: | Notebook computers |
| UNSPSC: | 43211503 |
| Manufacturer: | Lenovo |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Notebook computers |
| Description | Lenovo Legion Y540-15IRH-PG0 81SY - Core i7 9750H / 2.6 GHz - Win 10 Pro 64-bit - 16 GB RAM - 256 GB SSD NVMe + 1 TB HDD - 15.6" IPS 1920 x 1080 (Full HD) @ 60 Hz - GF GTX 1650 - 802.11ac, Bluetooth - black - kbd: US |
| Manufacturer | Lenovo |
| UNSPSC | 43211503 |
| Main Specifications | |
| Audio Input / Type | Dual array microphone |
| Dimensions & Weight / Depth | 26.7 cm |
| Dimensions & Weight / Height | 2.52 cm |
| Dimensions & Weight / Weight | 2.3 kg |
| Dimensions & Weight / Width | 36 cm |
| Display / Diagonal Size | 15.6 in |
| Display / Diagonal Size (metric) | 39.6 cm |
| Display / Native Resolution | 1920 x 1080 |
| Display / Type | LED |
| Display / Widescreen Display | Yes |
| Hard Drive / Capacity | 256 GB |
| Header / Brand | Lenovo |
| Header / Country Kits | United States |
| Header / Localization | English |
| Input Device / Type |
|
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 10 Pro 64-bit Edition |
| Packaged Quantity | 1 |
| Processor / Generation | 9 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 6-core |
| Processor / Processor Number | I7-9750H |
| Processor / Type | Core i7 |
| RAM / Form Factor | SO-DIMM 260-pin |
| RAM / Memory Speed | 2666 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 1-year warranty |
| System / Hard Drive Capacity | 1.256 TB |
| System / Notebook Type | Notebook |
| Video Output / Graphics Processor | NVIDIA GeForce GTX 1650 |
| AC Adapter | |
| Input | AC 120/230 V (50/60 Hz) |
| Output | 170 Watt |
| Audio & Video | |
| Audio Features | Output: Harman audio technology |
| Camera | Yes - 720p |
| Camera Features | Privacy shutter |
| Codec | Realtek ALC3287 |
| Compliant Standards | High Definition Audio, Dolby Atmos |
| Gaming | Yes |
| Graphics Processor | NVIDIA GeForce GTX 1650 |
| Resolution | 1 Megapixel |
| Sound | Stereo speakers, dual array microphone |
| Video Memory | 4 GB GDDR5 SDRAM |
| VR Ready | Yes |
| Battery | |
| Capacity | 57 Wh |
| Run Time | Up to 5 hours |
| Technology | 3-cell lithium ion |
| Communications | |
| Network Interface | Gigabit Ethernet |
| Wireless | 802.11a/b/g/n/ac, Bluetooth 4.1 |
| Wireless Controller | M.2 Card |
| Connections & Expansion | |
| Interfaces Details |
|
| Dimensions & Weight | |
| Dimensions (WxDxH) | 36 cm x 26.7 cm x 2.52 cm |
| Weight | 2.3 kg |
| Display | |
| Color Gamut | 45% |
| Features | Anti-glare |
| Image Aspect Ratio | 16:9 |
| Image Brightness | 250 cd/m² |
| LCD Backlight Technology | LED backlight |
| Resolution | 1920 x 1080 (Full HD) |
| Type | 15.6" - IPS |
| V-Sync Rate at Max Res. | 60 Hz |
| Widescreen | Yes |
| General | |
| Operating System | Windows 10 Pro 64-bit Edition - English |
| Product Type | Notebook |
| Input | |
| Features | Multi-touch touchpad, white LED backlight |
| Keyboard Backlight | Yes |
| Keyboard Layout | US |
| Numeric Keypad | Yes |
| Type | Keyboard, touchpad |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year |
| Memory | |
| Form Factor | SO-DIMM 260-pin |
| Max RAM Supported | 32 GB |
| RAM | 16 GB |
| Slots Qty | 2 |
| Speed | 2666 MT/s |
| Technology | DDR4 SDRAM |
| Miscellaneous | |
| Case Material | Polycarbonate ABS |
| Color | Black |
| Compliant Standards | RoHS, Energy-Related Products (ErP) Lot 3 |
| Features | Hard drive password, power-on password, LED lighting |
| Included Accessories | Power adapter |
| Localization | Language: English / region: United States |
| Security | Firmware Trusted Platform Module (TPM 2.0) Security Chip |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Processor / Chipset | |
| 64-bit Computing | Yes |
| Cache | 12 MB |
| CPU | Intel Core i7 (9th Gen) 9750H / 2.6 GHz |
| Features | Integrated memory controller |
| Max Turbo Speed | 4.5 GHz |
| Number of Cores | 6-core |
| Storage | |
| Main Storage | 256 GB SSD M.2 PCIe - NVM Express (NVMe) |
| Secondary Storage | 1 TB HDD SATA 6Gb/s / 7200 rpm |
